Specifications | |||
| Table Size | : | 12" x 8-1/16" (305 mm (X) x 205 mm (Y)) | ||
| Maximum cutting size | : | 12" x 8-1/16" (305 mm (X) x 205 mm (Y)) | ||
| Feed Rate | : | X, Y-axis. Max 118-1/16" (3.0m)/min 1-15/16 " (50 mm) /sec | ||
| Mechanical resolution | : | 0.000394
"(0.01 mm)/step 0.0000492 (0.00125mm)/step (micro-step control) |
||
| Software resolution | : | 0.000394" (0.01 mm)/step | ||
| Spindle Motor | : | 15W (DC Motor) | ||
| Revolution speed | : | 5,000 to 10,000 rpm | ||
| Interface | : | Parallel
(In compliance with the specification of Centronics) Serial (under RS-232C standard) Automatic switching |
||
| Buffer Size | : | 2 KB | ||
| Power consumption | : | 0.6A/117V, 0.4A/220 to 230V, 0.4A/230 to 240V | ||
|
External dimenison
(W x D x H) |
: | 20-1/4" x 19.3/8" x 8-9/16 " (513 mm x 491 mm x 217 mm) | ||
| Weight | : | 15.5 kg (34.2 lb) | ||
| Software included | : | Dr Engrave | ||
|
|
Compactness | |||
|
The machine fits readily into offices, shops and even homes. The work area is only 12 " x 8-1/16". It operates quietly. |
||||
|
|
Easy Operations | |||
|
The machine comes with a user friendly knobs on control panel for easy adjustment of feed rate and spindle RPM. It bundles with the Dr Engrave software to automatically convert your data to an engraving path for engraving to start. |
||||
|
|
Precision | |||
|
It operates on the industry standard of 0.125 inch diameter spindle : Professional grade precision and performance for your trophy plates, awards, badges, nametags and much more. |
||||
|
|
||||
